Folding and sliding doors
Jansen steel profiles create large-area and torsion-resistant door systems with slender frames.The profile and seal ranges are suitable for manual and automatic door systems. The Jansen folding and door systems are CE-compliant and fulfil the requirements of product standard EN 13241-1.
The compatibility of Janisol door systems guarantees visually uniform solutions even when there are a number of different security requirements: Non-insulated Jansen Economy door for indoor use and smoke protection as well as Janisol 2, Janisol C4 and highly thermally insulated Janisol HI systems can all be combined.
Product details
Materials / surface finish
Uncoated steel, suitable for powder coating or stove-enamelling
Element types
- Manual and automatic folding doors
- Automatic sliding-folding doors
- Manual and automatic sliding doors
- Any choice of leaf subdivision
- Folding door opening inwards or outwards
- Fully or partially sheet metal clad
Equipment
- Automatic drive
- Anti-finger-trap versions
- With insulating glazing or infill panels
- With integrated espagnolette bolt
Special technical features
- Construction depths 50, 60, 80 mm
- Sliding doors can be supplied with top or bottom tracks
- Installation behind, between or in front of the reveals
Test certificates, folding doors
- CE marking in accordance with product standard EN 13241-1
- Tightness against heavy rain up to class 3
- Air permeability up to class 4
- Resistance to wind load up to class 5
- Operating forces and user safety in accordance with EN 12453
Test certificates, sliding door>
- CE marking in accordance with product standard EN 13241-1
- Tightness against heavy rain up to class 3
- Air permeability up to class 1
- Resistance to wind load up to class 4
- Operating forces and user safety in accordance with EN 12453
